The LC-P Series Pulsed Fiber Laser Cleaning Machine (manufactured by Shenzhen Dapeng Laser Equipment Co., Ltd.) is a next-generation industrial cleaning solution designed to replace traditional chemical cleaning and mechanical polishing. It utilizes high-energy pulsed fiber laser (1064 nm wavelength) to remove contaminants via photothermal and photochemical effects, ensuring efficient, precise, and eco-friendly cleaning. Suitable for both handheld and automated integration, this machine caters to diverse industrial needs, from small-batch precision cleaning to large-scale batch processing.
Non-Contact & Substrate-Safe Cleaning: No physical contact with the workpiece eliminates scratches, deformation, or stress damage—ideal for fragile materials (e.g., semiconductors, cultural heritage) and high-value components.
Environmentally Friendly & Low Operating Cost: No chemical cleaners or consumables; only electricity is used. Removed contaminants (rust, paint, oil) can be recycled, avoiding secondary pollution.
High Precision & Adjustable Scanning: Scanning width ranges from 5 mm to 150 mm, with micrometer-level positioning accuracy. Ultraviolet laser options (355 nm) support nanoscale cleaning for semiconductors.
Portable & User-Friendly: Lightweight cleaning head (1.3–2 kg) with ergonomic shoulder straps reduces operator fatigue. Beginner-friendly interface and red-light assisted positioning enable easy operation.
Parameter | LC-P-100W | LC-P-300W | LC-P-500W | LC-P-1000W |
Average Power | 100W | 300W | 500W | 1000W |
Central Wavelength | 1064 nm | 1064 nm | 1064 nm | 1064 nm |
Scanning Area | 5–150 mm | 5–150 mm | 5–150 mm | 5–150 mm |
Cooling Method | Air-Cooled | Air-Cooled | Liquid-Cooled | Liquid-Cooled |
Cleaning Head Weight | 1.3 kg | 1.3 kg | 2 kg | 2 kg |
Power Supply | AC220V/50Hz | AC220V/50Hz | AC220V/50Hz | AC380V/50Hz |
Net Weight | 22 kg | 32 kg | 180 kg | 220 kg |
Operating Temperature | 0–45℃ | 0–45℃ | 0–45℃ | 0–45℃ |
Automotive Industry: Remove rust, oil stains, and paint from car bodies, engine parts, and welding joints.
Aerospace & Marine: Clean oxide layers on aluminum alloy components (aircraft) and ship hull paint without substrate damage.
Electronics & Semiconductors: Precision cleaning of circuit boards, semiconductor wafers, and electronic component oxides.
Heritage Conservation: Gentle removal of dirt and aging layers from cultural relics (stone, metal) without altering original surfaces.
Appearance Customization: Laser engraving of logos (vector graphics supported) and Pantone color matching for equipment shells.
Functional Customization: Tailored scanning patterns and power parameters for specific materials (e.g., thick steel rust, thin plastic coatings).
System Customization: Multi-language UI (English, German, Spanish) and PLC reprogramming to integrate with existing production lines.
Warranty: 2-year comprehensive warranty for the entire machine, covering laser generators and control systems.
Training: Lifetime free online technical training; on-site training at domestic centers after installation until operators master skills.
Support: 72-hour response for maintenance requests; global on-site installation and calibration support.
Can I request sample testing to verify cleaning effectiveness?
Yes. Sample testing is available with a fee (deductible from bulk orders). Test reports include metallurgical analysis, surface roughness, and laser spot diameter data.
Is the machine suitable for outdoor on-site cleaning?
Yes. The portable design (with universal wheels) and air-cooled models (LC-P-100W/300W) are ideal for outdoor use, such as on-site ship or bridge cleaning.
